PRODUCT DETAILS
The SDMT06T208 model is tailored for high-feed face milling on smaller diameter cutters or tighter area operations. Its compact inscribed circle and optimized chipbreaker allow high-feed speeds while maintaining excellent surface finish and dimensional precision.
Key Features
Suitable for small cutter face milling applications.
Compact geometry reduces cutting resistance and improves stability.
Excellent chip evacuation under high-feed conditions.
Recommended grades: PA1025 / PA1825 / MA1525.
Ideal for steel & stainless steel plates, blocks, finishing + semi-finishing.
SDMT06T208 Size:
|
Length |
Size(mm) |
||
| IC | S | r | |
| 6 | 6.35 | 2.5 8 | 0.8 |
SDMT06T208 Specifications:
| Model |
ap (mm) |
f (mm/rev) |
Grade |
|||||||
|
CVD |
PVD |
|||||||||
| KA3115 | PA4215 | PA4225 | PA1025 | PA1825 | MA1525 | SA1520 | SA1525 | |||
| SDMT06T208-GH | 0.5-1.2 | 0.50-1.00 | ● | ● | ● |
|
||||
Inserts Grade Information:
| ISO | Application | CVD | PVD |
| P | Steel | PA4215/PA4225/PA4235 | PA1015/PA1025/PA1825 |
| M | Stainless steel | MA1820/MA1824/MA1828/MA1525 | |
| K | Cast iron | KA3020/KA3040/KA3115 | |
| S |
Superalloy |
SA1029/SA1510/SA1525/SA1605/SA1610 | |
| N | Aluminum | NA10 | |
| H | High hardness material | HA1009 |
