PRODUCT DETAILS
The CNMG190616 is made for extreme cutting conditions. With a reinforced body and advanced coating, it handles the toughest roughing operations with consistency.
Key Features:
Superior toughness under shock load
Long tool life at high temperatures
Consistent cutting under vibration
Suitable for continuous and interrupted cutting
Applications:
Heavy roughing of hardened steel
CNC and industrial metal removal
CNMG190616 Size:
| Length | Size(mm) | |||
| IC | S | d | r | |
| 19 | 19.05 | 6.35 | 7.94 | 1.6 |
CNMG190616 Specifications:
| Model |
ap (mm) |
f (mm/rev) |
Grade | ||||||
| CVD | PVD | ||||||||
| KA3115 | PA4215 | PA4225 | PA1825 | MA1828 | SA1610 | SA1525 | |||
| CNMG190616-AS | 2.4-9.7 | 0.40-1.20 | ● | ||||||
| CNMG190616-AR | 2.9-7.7 | 0.25-0.50 | ● | ||||||
| CNMG190616 | 0.8-12 | 0.20-1.00 | ● | ||||||
CNMG190616 Chip Breaker:
| Chip Breaker | Application | Features |
| AS |
Steel Semi-finishing |
M-level double-sided chip breaker, negative chamfer design, high edge strength, suitable for semi-finishing occasions with unstable working conditions. |
| AR | Steel Roughing | The preferred chip breaker for lightload roughing, wide margin design, good edge strength, high metal removal rate, good wear resistance and cutting life. |
Inserts Grade Information:
| ISO | Application | CVD | PVD |
| P | Steel | PA4215/PA4225/PA4235 | PA1015/PA1025/PA1825 |
| M | Stainless steel | MA1820/MA1824/MA1828/MA1525 | |
| K | Cast iron | KA3020/KA3040/KA3115 | |
| S |
Superalloy |
SA1029/SA1510/SA1525/SA1605/SA1610 | |
| N | Aluminum | NA10 | |
| H | High hardness material | HA1009 |
