HT Series Single Tooth Solid Carbide Thread Mill for Alloy Steel, Stainless & Titanium | Factory Direct

The HT Series Single Tooth Solid Carbide Thread Mill is a high-performance universal threading solution for CNC machining of tough materials such as 40Cr, Cr12, SUS stainless steel, P20, S136, 718 mold steel, manganese steel, titanium alloy, and martensitic stainless iron.
Engineered for precision and stability, this tool is capable of machining 60° metric and UNC threads, both internal and external, including tapered and multi-pitch threads. The single-flute design ensures smooth chip evacuation and consistent thread profiles even in deep holes or hard-to-machine materials.

Perfect for manufacturers seeking a versatile carbide thread mill that performs reliably across various metals and machining setups.

Features & Advantages

1. Wide Material Compatibility – Suitable for alloy steel (40Cr, Cr12), stainless steel (SUS), mold steels (P20, 718, S136), titanium alloy, and cast/manganese steels.

2. Universal Threading Capability – Supports 60° metric, UNC, and tapered threads with adjustable pitch.

3. Single Flute Design – Delivers excellent chip evacuation, superior surface finish, and high tool stability.

4. Dual Direction Threading – Can machine both right-hand and left-hand threads with one tool.

5. High Precision & Long Tool Life – Made from ultra-fine grain tungsten carbide for maximum wear resistance and dimensional accuracy.

6. Excellent for Nut and Blind Hole Machining – Perfect for internal thread applications requiring clean entry and exit.

7. Optimized for CNC Centers – Compatible with most modern CNC thread milling toolpaths and controllers.

Optional Customization

• Coatings: TiAlN, AlTiN, DLC for enhanced performance on specific materials

• Shank types: Straight / Weldon / Necked for deep hole machining

• Thread standards: Metric, UNC, UNF, BSP, NPT available

• OEM / ODM service: Custom tool geometry, diameter, flute length, and laser marking with your brand

Applications

• Precision CNC machining of alloy steel and stainless components

• Mold manufacturing and die-thread cutting

• Aerospace and medical part threading in titanium alloys

• High-performance thread production in hard or abrasive materials

Available Sizes and Specifications:

ITEM		Pitch(mm)	d	L1	D	L	Flutes	Hole diameter
Coarse teeth	Fine teeth
HT-M0.6*0.15-T1-L50		0.15	0.43	1.2	4	50	3	0.45
HT-M0.8*0.2-T1-L50		0.2	0.55	2	4	50	3	0.6
HT-M0.9*0.225-T1-L50		0.225	0.6	2	4	50	3	0.675
HT-M1*0.25-T1-L50		0.25	0.73	2.3	4	50	3	0.75
HT-M1.2*0.25-T1-L50		0.25	0.92	2.8	4	50	3	0.95
HT-M1.4*0.3-T1-L50		0.3	1.05	3.2	4	50	3	1.1
HT-M1.6*0.35-T1-L50		0.35	1.21	3.5	4	50	3	1.25
HT-M2*0.4-T1-L50		0.4	1.54	4.5	4	50	3	1.6
HT-M2.5*0.45-T1-L50		0.45	1.96	5.5	4	50	3	2.05
HT-M3*0.5-T1-L50		0.5	2.4	7	4	50	3	2.5
HT-M4*0.7-T1-L50		0.7	3.15	8.6	4	50	4	3.3
HT-M5*0.8-T1-L50		0.8	4	12	4	50	4	4.2
HT-M5*0.8-T1-L50		0.8	4	13	6	50	4	4.2
	HT-M6*0.5-T1-L50	0.5	5	16	6	50	4	5.5
	HT-M6*0.75-T1-L50	0.75	5	16	6	50	4	5.25
HT-M6*1.0-T1-L50		1	4.75	15	6	50	4	5
	HT-M8*0.5-T1-L50	0.5	6	16	6	50	4	7.5
	HT-M8*0.75-T1-L50	0.75	6	16	6	50	4	7.25
	HT-M8*1.0-T1-L50	1	6	16	6	50	4	7
HT-M8*1.25-T1-L60		1.25	5.95	20	6	60	4	6.75
	HT-M10*0.5-T1-L60	0.5	8	25	8	60	4	9.5
	HT-M10*0.75-T1-L60	0.75	8	25	8	60	4	9.25
	HT-M10*1.0-T1-L60	1	8	25	8	60	4	9
	HT-M10*1.25-T1-L60	1.25	8	25	8	60	4	8.75
HT-M10*1.5-T1-L60		1.5	7.9	25	8	60	6	8.5
	HT-M12*0.5-T1-L75	0.5	10	30	10	75	5	11.5
	HT-M12*0.75-T1-L75	0.75	10	30	10	75	5	11.25
	HT-M12*1.0-T1-L75	1	10	30	10	75	5	11
	HT-M12*1.25-T1-L75	1.25	10	30	10	75	5	10.75
	HT-M12*1.5-T1-L75	1.5	10	30	10	75	5	10.5
HT-M12*1.75-T1-L75		1.75	9.9	30	10	75	6	10.25
	HT-M14*1.0-T1-L75	1	Previous Product GT Series Single Tooth Carbide Thread Mill Next Product ST Series Single Tooth Carbide Thread Mill Related Products Explore more cutting tools from the same series or for similar applications UN Series 3 Teeth Carbide Thread Mill Teeth: 3 Teeth Suitable for: Steel / Stainless steel View Details G55 Series Single Tooth Solid Carbide Thread Mill Tooth: Single Tooth Suitable for: Steel View Details ST Series Single Tooth Carbide Thread Mill Tooth: Single Tooth Suitable for: Stainless steel / Titanium alloys View Details AL Series 3 Teeth Solid Carbide Thread Mill Teeth: 3 Teeth Suitable for: Aluminum alloys View Details Related Articles Technical insights and buying guides to help you choose the right cutting tools  What are U drills?  How to Maintain and Clean Carbide Drill Bits with Coolant Holes  Common Failures in Metric Thread Turning and Fixes Using Carbide Inserts  Struggling with Drill Bit Overheating? Consider Carbide Options  How to Avoid Burrs and Wire Edges When Using Chamfer Mills on Aluminum or Steel  How hard are HSS thread taps? Request a Quote / Technical Inquiry Tell us your material, Product size and quantity. Our engineer will reply within 24 hours. Your Name * Email Address * Inquiry Details * Submit Inquiry Success Thank you, We Will Call You Back Soon! OK Error Submission failed, please try again. OK Ready to Improve Your Machining Performance? Contact our experts today for a free quote or technical consultation. Get a Free Quote
