PRODUCT DETAILS
Carbide Unified (UN) 60° Thread Inserts are top-tier cutting tools designed for precise threading in industrial applications. Crafted from premium carbide material, these inserts ensure superior wear resistance and can endure high-stress cutting, providing reliable performance in various conditions.
Features:
Precision Cutting: Designed for external threading, these inserts guarantee accurate thread formation, adhering to industry standards for quality and consistency.
High Efficiency: The unique geometry of these inserts reduces cutting forces, improving production efficiency and ensuring seamless cutting operations.
Wide Compatibility: Compatible with a wide range of lathes and milling machines, making them versatile for different threading needs.
Application Areas:Ideal for use in the automotive, aerospace, and machinery manufacturing industries, these inserts are perfect for high-precision threading tasks. Whether you're handling large-scale production or custom small-batch projects, Carbide Unified (UN) 60° Thread Inserts deliver dependable cutting solutions.
Keywords:Carbide thread inserts, UN 60° thread, precision cutting, high efficiency, wide compatibility, automotive threading, aerospace threading, machinery manufacturing.
Choose Carbide Unified (UN) 60° Thread Inserts to enhance your machining efficiency and product quality. Order now to experience professional-grade cutting performance!
| Model | TPI | IC(inch) | L(mm) | X(mm) | Y(mm) |
| 11IR/IL-14UN | 14 | 1/4" | 32 | 0.8 | 0.8 |
| 11IR/IL-16UN | 16 | 1/4" | 32 | 0.8 | 0.8 |
| 11IR/IL-18UN | 18 | 1/4" | 32 | 0.8 | 0.8 |
| 11IR/IL-20UN | 20 | 1/4" | 32 | 0.8 | 0.8 |
| 11IR/IL-24UN | 24 | 1/4" | 32 | 0.8 | 0.8 |
| 11IR/IL-28UN | 28 | 1/4" | 32 | 0.8 | 0.8 |
| 11IR/IL-32UN | 32 | 1/4" | 32 | 0.8 | 0.8 |
| 16ER/EL/IR/IL-8UN | 8 | 3/8" | 16.5 | 1.2 | 1.5 |
| 16ER/EL/IR/IL-9UN | 9 | 3/8" | 16.5 | 1.2 | 1.5 |
| 16ER/EL/IR/IL-10UN | 10 | 3/8" | 16.5 | 1.2 | 1.5 |
| 16ER/EL/IR/IL-11UN | 11 | 3/8" | 16.5 | 1.2 | 1.5 |
| 16ER/EL/IR/IL-12UN | 12 | 3/8" | 16.5 | 1.2 | 1.5 |
| 16ER/EL/IR/IL-14UN | 14 | 3/8" | 16.5 | 1.2 | 1.5 |
| 16ER/EL/IR/IL-16UN | 16 | 3/8" | 16.5 | 0.8 | 0.8 |
| 16ER/EL/IR/IL-18UN | 18 | 3/8" | 16.5 | 0.8 | 0.8 |
| 16ER/EL/IR/IL-20UN | 20 | 3/8" | 16.5 | 0.8 | 0.8 |
| 16ER/EL/IR/IL-24UN | 24 | 3/8" | 16.5 | 0.8 | 0.8 |
| 16ER/EL/IR/IL-28UN | 28 | 3/8" | 16.5 | 0.8 | 0.8 |
| 16ER/EL/IR/IL-32UN | 32 | 3/8" | 16.5 | 0.8 | 0.8 |
| 22ER/EL/IR/IL-5UN | 5 | 1/2" | 22 | 1.8 | 2.5 |
| 22ER/EL/IR/IL-6UN | 6 | 1/2" | 22 | 2.2 | 2.5 |
| 22ER/EL/IR/IL-7UN | 7 | 1/2" | 22 | 2.0 | 2.5 |
| 27ER/EL/IR/IL-4UN | 4 | 5/8" | 27.5 | 2.2 | 3.2 |
| 27ER/EL/IR/IL-4.5UN | 4.5 | 5/8" | 27.5 | 2.2 | 3.2 |
